Description
Double Wall Heat Shrink Tube
Features
Meets UL class of high temperature integrated tube compatible AMS-DTL = 23053/5 and UL 224 , CAN / CSA C22.2 NO198.1 -99
Heat shrink ratio: 2:1
Low smoke generation, flexible, flame retardant
Min. shrink temperature:84°C
Min. Full recovery temperature:120°C
Continuous operating temperature : -55°C ~ 150°C
RoHS compliant
Standard colors: Black. More colors are available upon request.
Technical Data
| Properties | Typical Data | Test Method |
| Tensile strength | ≥10.4MPa | ASTM D 2671 |
| Elongation | ≥200% | ASTM D 2671 |
| Tensile strength after heat aging | ≥7.3MPa | 180℃×168h |
| Elongation after heat aging | ≥100% | 180℃×168h |
| Longitudinal change | -5%~+5% | ASTM D 2671 |
| Flammability | VW-1 | ASTM D 2671 C |
| Voltage withstand(Rated voltage 600V) | 2500V,1min, without breakdown | UL 224 |
| Heat shock | No cracking, no dripping | UL 224,250℃×4h |
| Dielectric strength | ≥15kV/mm | ASTM D 149 |
| Volume resistivity | ≥1014Ω.cm | IEC 60093 |
Structure
